| Swing | 35.6" | 904.24 mm |
| Machining Length | 29.3" | 744.22 mm |
| # Axis | 4 | 4 |
| Chuck Size | 18" | 457.2 mm |
| Bar Capacity | 7.3" | 185.42 mm |
| Power | 50 hp | 37.3 kW |
| Max RPM | 2,000 RPM | 2,000 RPM |
| Turning Dia | 23.6" | 599.44 mm |
| Tailstock | Yes | Yes |
| Live Tooling | Yes | Yes |
| Sub Spindle | No | No |
| Control | CNC | CNC |
Max. Turning Diameter: 23.6"
Max. Turning Length: 29.3"
Max. Swing Diameter: 35.6"
Chuck Size: 18"
X-Axis: 14.4"
Y-Axis: 4.7"
Z-Axis: 34.4"
Max. Spindle Speed: 2,000 RPM
Hours: Less Than 4,500
Mori M730BM Control
Kitagawa 18" Chuck
Programmable Tailstock
1,000 PSI High Pressure Coolant Interface
CoolJet 70/36 HP Coolant System
75 KVA 480/220V Transformer
This equipment has been sold. Similar equipment available now is shown below.
