Capacity
20" Swing Over Bed
11" Swing Over Cross Slide
30" Maximum Turning Length
Spindle
1,800 RPM
A2-5 Spindle Nose
1.75" Bar Capacity
7.5 HP Spindle Motor
Chuck
8" Manual Chuck
Axis Travel
8" X-Axis
30" Z-Axis
Feedrates
400 IPM Rapid Traverse X
400 IPM Rapid Traverse Z
Tailstock
Manual Tailstock
2.5" Quill Diameter
3" Quill Travel
Tooling
Manual Tool Post
4-Position Tool Capacity
Electrical
208 / 230 Volt
3 Phase
60 Hz
Machine Weight
Approx. 3,000 Lbs
Haas CNC Control
Manual Tool Post
Manual Tailstock
Toolroom Lathe Configuration
