| X | 50" | 1,270 mm |
| Y | 20" | 508 mm |
| Z | 25" | 635 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 7,500 RPM | 7,500 RPM |
| # ATC | 20 | 20 |
| Taper | CAT 40 | CAT 40 |
| Table-W | 18" | 457.2 mm |
| Table-L | 52" | 1,320.8 mm |
| Dimensions | 152 x 99 x 106 in | 152 x 99 x 106 in |
| Weight | 12000 lbs | 12000 lbs |
X-Axis Travel: 50″
Y-Axis Travel: 20″
Z-Axis Travel: 25″
Table Dimensions: 52″ x 18″
Maximum Weight Capacity: 3,500 lbs
Motor Power: 30 hp
Speed Range: 7,500 rpm
Taper: CAT 40
Tool Capacity: 20-tool ATC
Rapid Traverse Rate (X, Y, Z): 710 ipm
Approx. Machine Dimensions: 152″ x 99″ x 106″
Approx. Machine Weight: 12,000 lbs
All specifications are assumed to be correct but must be confirmed by the purchasing entity.
