Key Features:
Dual unwinds with adhesive & substrate air shafts
Edge guide sensors for both adhesive and substrate for precise alignment
Integrated HMI & gauge display for real-time process monitoring
Cut guides for both adhesive and substrate
Specifications:
Maximum material width: 60″
Overall dimensions: 11′ L x 7′ W x 9′ H
Electrical: 208/120V (4-wire), 3 phase, 30 amps, 60 Hz
Air: 80–120 PSI @ 5 SCFM
Largest motor: 1 HP
Additional specs on nameplate (attached)
Applications:
Multi-layer lamination of elastomers, foams, and films
PSA application with accurate edge alignment
All specifications are assumed to be correct but must be confirmed by the purchasing entity.
This equipment has been sold. Similar equipment available now is shown below.
