| Swing | 3.94" | 100.08 mm |
| Centers | 15.7" | 398.78 mm |
| Power | 5 hp | 3.7 kW |
| Workhead Power | 0.5 hp | 0.4 kW |
| Workhead Speed | 0 RPM | 0 RPM |
| Grinding Wheel Dia. | 14" | 355.6 mm |
| Max Weight Between Centers | 110 lb | 49.9 kg |
| Control | CNC (Mitsubishi GOT1000) | CNC (Mitsubishi GOT1000) |
| Dimensions | 93.7 in x 65 in x 68 in | 93.7 in x 65 in x 68 in |
| Weight | 4840 lbs | 4840 lbs |
Specifications (subject to buyer verification):
Distance Between Centers: 15.7″
Maximum Grinding Diameter: 3.94″
Maximum Weight of Workpiece Between Centers: 110 lbs
Control: Mitsubishi GOT1000
Wheelhead:
Wheel Size (OD x Width x ID): 14″ x 1″ x 5″
Wheel Speed: 1800 RPM
Wheel Motor: 5 HP
Workhead:
Swivel Range: ±30°
Workhead Spindle Speed: 30 – 600 RPM
Workhead Motor: 0.5 HP
Table:
Swivel Range: ±9°
Traverse Speed: 0.04 – 157.5 ipm
Minimum Increment: 0.000004″
Rapid Traverse: 236 ipm
Tailstock Center Taper: MT3
Machine Dimensions:
Approx. Dimensions: 93.7″ x 65″ x 68″
Approx. Weight: 4840 lbs
All specifications are assumed to be correct but must be confirmed by the purchasing entity.
