| X | 64" | 1,625.6 mm |
| Y | 32" | 812.8 mm |
| Z | 30" | 762 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 24 | 24 |
| Taper | CT or BT 40 | CT or BT 40 |
| Table-W | 64" | 1,625.6 mm |
| Table-L | 28" | 711.2 mm |
| # Axis | 3 | 3 |
Excellent Condition
12,000 RPM Inline Direct Drive
Cat-40
64" X Travel
32" Y Travel
30" Z Travel
64" x 28" Table Area
24 +1 Side Mount Tool Changer
4th-Axis
Wireless Intuitive Probing System (Renishaw WIPS)
Programmable Coolant & Automatic Air Gun (constant air blast to clear chips during dry machining)
High Speed Machining
Rigid Tapping
Visual Part Programing
Spindle Orientation
Coordinate Rotation and Scaling
User Definable Macros
Remote Jog Handle
750MB Expanded Memory / Ethernet
Fixture Plate
High Intensity Lighting
Chip Auger
95 Gallon Coolant Tank
30 HP Motor
All specifications are assumed to be correct but must be confirmed by the purchasing entity.
