| X | 126" | 3,200.4 mm |
| Y | 82.7" | 2,100.6 mm |
| Z | 35.4" | 899.16 mm |
| Power | 75 hp | 55.9 kW |
| RPM | 18,000 RPM | 18,000 RPM |
| # ATC | 40 | 40 |
| Taper | HSK 63 | HSK 63 |
| Table-W | 66.9" | 1,699.3 mm |
| Table-L | 118.1" | 2,999.7 mm |
X 126″
Y 82.7″
Z 35.4″
Power 75 hp
RPM 18,000 RPM
# ATC 40
Taper HSK
Table-W 66.9″
Table-L 118.1″
Control CNC (Hurco Winmax)
Dimensions 393.0” W x 268.3” D x 207.0” H
Weight 81,064 lbs
All specifications are assumed to be correct but must be confirmed by the purchasing entity.
WinMax CNC Control
Box Way Ram on Z Axis
Direct Drive ballscrews X/Y/Z
Direct-Drive B/C Axis Head
Full Enclosure with Wide Access Doors
Right and Left Side LED Work Lights
Electric Swing-Arm ATC – Random Access
Enclosure Washdown System
Oil Skimmer Assembly
Spindle Thermal Chiller
Coolant Through Spindle (725 PSI)
Air Through the Spindle (85 psi)*
Flood Coolant
Internal Augers & Lift-Up Chip Conveyor
Air Blow Machining
Power Cabinet Heat Exchanger
Way Lube Separation System
Liner Glass Scales
Advanced Verification Graphic
DXF
NC Productivity Package
Industry Standard NC
Tool Prob
Part Prob
Ulti-Pocket
Insert Pocket
Rigid Tap
Helical Ramp
3D Mold
NC Conversational Merge
Swep Surface
Select Surface Finish Quality
Tool & Material Library
Ulti-Motion
Simultaneous 5 Axis
Tool Change Optimization
Ulti-Monitor
Stream Load
