| X | 30" | 762 mm |
| Y | 20" | 508 mm |
| Z | 20" | 508 mm |
| # Axis | 5 | 5 |
| Power | 30 hp | 22.4 kW |
| RPM | 15,000 RPM | 15,000 RPM |
| # ATC | 40 | 40 |
| Taper | CT or BT 40 | CT or BT 40 |
| Table-W | 19.7" | 500.38 mm |
| Table-L | 24.8" | 629.92 mm |
X-Axis Travel: 30″
Y-Axis Travel: 20″
Z-Axis Travel: 20″
Spindle Speed: 15,000 RPM
Spindle Motor: 30 HP
Tool Changer: 40 + 1 Side Mount
Rapids: 1200 ipm
Spindle Taper: BT 40
Equipped With:
Haas Control
Belt Type Conveyor
Programmable Coolant Nozzle
Auxiliary Coolant Filter
300 PSI Through Spindle Coolant
WIPS
All specifications are assumed to be correct but must be confirmed by the purchasing entity.
