Capacity: 247.5 tons
Bending Length: 157.5″
Distance Between Housings: 124″
Max Stroke: 10.24″
Open Height Without Tools (A): 19.69″
Throat Depth (B): 15.75″
Motor Power: 20.1 hp
Approach Speed: 5.12 in/sec
Working Speed: 0.31 in/sec
Return Speed: 3.35 in/sec
Stroke of Axis X: 24.61″
Speed of Axis X: 19.69 in/sec
Stroke of Axis R: 7.87″
Speed of Axis R: 1.97 in/sec
Stroke of Axes Z1/Z2: 108.27″
Speed of Axis Z1/Z2: 15.75 in/sec
Min. Machine Length: 196.06″
Max. Machine Length (C): 227.56″
Max. Width (D): 85.83″
Max. Height (E): 122.83″
Transportation Height: 113.39″
Approx. Weight: 29,762 lbs
Height of Work Station: 36.61″
All specifications are assumed to be correct but must be confirmed by the purchasing entity.
