| Tonnage | 220 T | 199.581 t |
| Overall Length | 4,250 mm | 13.94' |
| Stroke | 450 mm | 17.717" |
Tonnage: 242 Tons
Max Bending Length: 167″
Distance Between Side Frames: 145.5″
Open Height: 27.6″
Stroke: 17.7″
Throat Depth: 20.47″
Max Speed: 519 IPM
Bending Speed: 42 IPM
Main Motor: 35 H.P.
Dimensions: 210″ x 82″ x 146″
Weight: 52,600 Lbs. Approximate
Equipped with:
MVM Adjustable Bottom Die – up to 2″ Opening – Automatically Adapts the Opening of the Vee Opening Based on the Program
ATA – Automatically Adjusts the Upper Bending Tool Length
CNC Crowning
6 Axis Back Gauge
AMS – Angle Measurement System
Oil Cooler
Lazer Safe Safety Lights
5 Axis Back Gauge
12′ Length of 8″ Tall ATA Gooseneck Punch
Wila Hydraulic Top Clamping
All specifications are assumed to be correct but must be confirmed by the purchasing entity.
