| X | 22" | 558.8 mm |
| Y | 16" | 406.4 mm |
| Z | 22" | 558.8 mm |
| Power | 25 hp | 18.6 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 40 | 40 |
| Taper | CAT 40 | CAT 40 |
| Table-W | 19" | 482.6 mm |
| Table-L | 28" | 711.2 mm |
| # Axis | 3 | 3 |
| Dimensions | 113.8x94.1x122.4 | 113.8x94.1x122.4 |
| Weight | 17226 | 17226 |
Travel Distance X-Axis 560 Mm (22 In)
Travel Distance Y-Axis 430 Mm (16.9 In)
Travel Distance Z-Axis 570 Mm (22.4 In)
Rapid Traverse X-Axis 40 M/Min (1575 In/Min)
Rapid Traverse Y-Axis 40 M/Min (1575 In/Min)
Rapid Traverse Z-Axis 36 M/Min (1417 In/Min)
Number Of Pallets 2
Pallet Size 712 X 490 Mm (28 X 19.3 In)
Pallet Max Load 300 Kg (660 Lbs)
Speed 12000 Rpm
Power 18.5 Kw (25 Hp)
Torque 167.6 Nm (123.7 Ft-Lbs)
Shank Big Plus Bt 40
Changer Capacity 40
Max Diameter ⌀80/125 Mm (3.2/4.9 In)
Max Length 300 Mm (11.8 In)
Length 2890 Mm (113.8 In)
Height 3110 Mm (122.4 In)
Width 2391 Mm (94.1 In) + 946 Mm (37.2 In)
Weight 7830 Kg (17226 Lbs)
- Probe
- Tool Setter
