| X | 30" | 762 mm |
| Y | 22" | 558.8 mm |
| Z | 20" | 508 mm |
| # Axis | 5 | 5 |
| Power | 30 hp | 22.4 kW |
| RPM | 8,100 RPM | 8,100 RPM |
| # ATC | 41 | 41 |
| Taper | CT or BT 40 | CT or BT 40 |
| Table-W | 19.7" | 500.38 mm |
| Table-L | 24.8" | 629.92 mm |
| Dimensions | 96” x 160” x 110” | 96” x 160” x 110” |
| Weight | 20,000 LBS | 20,000 LBS |
Misc. Tooling
Haas CNC Control
WIPS Renishaw Probing
Through-Spindle Coolnt
12,000 RPM Spindle
5TH Axis Riser and Vice Included
40 Tool Positions
Max Memory 1GB
Rigid Tapping
Belt Type Chip Conveyor
High Speed Machining
Spindle Orientation
Macros
4TH Axis
5TH Axis
Wireless Networking
Rotation & Scaling
USB
Remote Jog
All specifications are assumed to be correct but must be confirmed by the purchasing entity.
